Page #37 background imageLoading...
Page #37 background image
5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 36 / 86
4 Application Interfaces
The physical connections and signal levels of RM500Q-AE and RM502Q-AE comply with the PCI
Express M.2 specification. This chapter mainly describes the definition and application of the following
interfaces/pins of the module:
(U)SIM interfaces
USB interface
PCIe interface
PCM interface
Control and indication interfaces
Cellular/WLAN COEX interface*
Antenna tuner control interface*
Configuration pins
4.1. (U)SIM Interface
The (U)SIM interface circuitry meets ETSI and IMT-2000 requirements. Both Class B (3.0 V) and Class C
(1.8 V) (U)SIM cards are supported.
4.1.1. Pin definition of (U)SIM
RM500Q-AE and RM502Q-AE support single (U)SIM slot.
Table 14: Pin Definition of (U)SIM Interface
Pin No.
Pin Name
I/O
Description
DC Characteristics
36
USIM1_VDD
PO
Power supply for (U)SIM1 card
1.8/3.0 V
34
USIM1_DATA
DIO, PU
(U)SIM1 card data
USIM1_VDD
1.8/3.0 V
32
USIM1_CLK
DO, PD
(U)SIM1 card clock
USIM1_VDD
1.8/3.0 V
30
USIM1_RST
DO, PD
(U)SIM1 card reset
USIM1_VDD
1.8/3.0 V
