Quectel 5G Module Series Hardware Design

5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 61 / 86
5.1.5. Output Power
The following table shows the RF output power of the module.
Table 34: Cellular Output Power
1)
For 5G NR TDD bands, the normative reference for this requirement is TS 38.101-1 clause 6.3.1.
5.2. GNSS Antenna Interface
5.2.1. General Description
The module includes a fully integrated global navigation satellite system solution (GPS, GLONASS,
BeiDou/COMPASS, and Galileo).
The module supports standard NMEA-0183 protocol, and outputs NMEA sentences at 1 Hz data update
rate via USB interface by default.
By default, the module GNSS engine is switched off. It must be switched on via AT command. For more
details about GNSS engine technology and configurations, see document [5].
Mode
Frequency
Max.
Min.
WCDMA
WCDMA bands
24 dBm +1/-3 dB (Class 3)
< -50 dBm
LTE
LTE bands
23 dBm ±2 dB (Class 3)
< -40 dBm
LTE HPUE bands
(B38/B40/B41/B42/B43)
26 dBm ±2 dB (Class 2)
< -40 dBm
5G NR
5G NR bands
23 dBm ±2 dB (Class 3)
< -40 dBm (BW: 5–20 MHz)
1)
5G NR HUPE bands
(n41/n77/n78/n79)
26 dBm +2/-3 dB (Class 2)
< -40 dBm (BW: 5–20 MHz)
1)
NOTE
