Quectel 5G Module Series Hardware Design

5G Module Series
RM500Q-AE&RM502Q-AE Hardware Design
RM500Q-AE&RM502Q-AE_Hardware_Design 60 / 86
1)
SIMO is a smart antenna technology that uses a single antenna at the transmitter side and two
antennas at the receiver side, which improves Rx performance.
5G NR-FDD n7 (20 MHz)
(SCS: 15 kHz)
-93.5
-94
-96.5
-92.0 dBm
5G NR-FDD n8 (20 MHz)
(SCS: 15 kHz)
-95.0
-97.0
-98.5
-90.0dBm
5G NR-FDD n12 (15 MHz)
(SCS: 15 kHz)
-95.0
-98.0
-99.5
-84.0 dBm
5G NR-FDD n20 (20 MHz)
(SCS: 15 kHz)
-95.0
-97.0
-99.0
-90.0 dBm
5G NR-FDD n25 (20 MHz)
(SCS: 15 kHz)
-94.5
-95.0
-97.5
-90.5 dBm
5G NR-FDD n28 (20 MHz)
(SCS: 15 kHz)
-95.0
-97.0
-99.0
-91.0 dBm
5G NR-TDD n38 (20 MHz)
(SCS: 30 kHz)
-94.0
-95.0
-97.0
-94.0 dBm
5G NR-TDD n40 (20 MHz)
(SCS: 30 kHz)
-93.5
-93.5
-95.5
-94.0 dBm
5G NR-TDD n41 (100 MHz)
(SCS: 30 kHz)
-85.0
-87.0
-88.5
-84.7 dBm
5G NR-FDD n48 (20 MHz)
(SCS: 30 kHz)
-94.0
-95.5
-97
-93.0 dBm
5G NR-FDD n66 (40 MHz)
(SCS: 15 kHz)
-91.5
-92.0
-94.5
-90.1 dBm
5G NR-FDD n71 (20 MHz)
(SCS: 15 kHz)
-95.0
-97.5
-99.5
-86.0 dBm
5G NR-TDD n77 (100 MHz)
(SCS: 30 kHz)
-86.0
-87.0
-89.0
-85.1 dBm
5G NR-TDD n78 (100 MHz)
(SCS: 30 kHz)
-86.0
-87.5
-89.0
-85.6 dBm
5G NR-TDD n79 (100 MHz)
(SCS: 30 kHz)
-86.0
-86.5
-89.5
-85.6 dBm
NOTE
