5.1.2. Port Mapping
Table 31: RM500Q-AE & RM502Q-AE Antenna Mapping
5.1.3. Operating Frequency
Table 32: RM500Q-AE&RM502Q-AE Operating Frequencies
1.
1)
NR TRX1 = TX MIMO + PRX MIMO; NR DRX1 = DRX MIMO.
2.
2)
UHB frequency range: 3400–3800 MHz.
Antenna
WCDMA
LTE
5G NR
LB
(MHz)
MHB
(MHz)
n77/n78
(MHz)
n79 (MHz)
Refarmed
n41
n77/n78/
n79
ANT0
MHB_TRX
MHB_TRX,
UHB_PRX
1)
MIMO
MHB_TRX,
UHB_PRX
1)
MIMO
TRX1
2)
PRX MIMO
-
1452–2690
3300–4200
4400–5000
ANT1
LB_TRX
LB_TRX,
MHB_DRX MIMO,
UHB_PRX
1)
MIMO,
LAA PRX
LB_TRX,
MHB_DRX
MIMO,
UHB_DRX
1)
MIMO,
DRX1
2)
DRX MIMO
617–960
1452–2690
3300–4200
4400–6000
ANT2
LB_DRX
LB_DRX,
MHB_PRX MIMO,
UHB_TRX
1)
LB_DRX,
MHB_PRX
MIMO,
UHB_TRX
1)
TRX0
2)
TRX
617–960
1452–2690
3300–4200
4400–5000
ANT3_
GNSSL1
MHB_DRX
MHB_DRX,
UHB_DRX
1)
,
LAA_DRX
MHB_DRX,
UHB_DRX
1)
,
DRX0
2)
DRX
-
1452–2690
3300–4200
4400–6000
1.
1)
UHB frequency range: 3400–3800 MHz.
2.
2)
NR TRX1 = TX MIMO + PRX MIMO; NR DRX1 = DRX MIMO.
Band Name
Transmit (MHz)
Receive (MHz)
LTE-FDD
LTE-TDD
UMTS
5G NR
IMT (2100)
1920–1980
2110–2170
B1
–
B1
n1
NOTES
NOTES
