(1) Roam Mode → press the [Select]-key → rotate the [ENC] knob or use the
[▲/▼]-keys to choose from one of the modes Auto, Manual or RSSI → press
the [Select]-key to confirm the selection and return to the previous level.
Once searching an available repeater from the scan list, the
radio will lock to the current available repeater and pause
auto roaming. Then, it will connect with the available
repeater according to the preset Connect Check Timer. If
the connection fails after the preset Connect Time is used
up, it will restart the strong signal Auto roaming search.
Users can manually roam to the next available repeater.
Once it is on, all repeater channels in the scan list will be
waken up to search the nearest available repeaters until
finds an available one. Every time the nearest available
repeater is found, a Connect Recheck Timer (Repeater
Check Timer) will be enabled. Users can also lock the
repeater by short pressing the [OK/Select]-key. The next
available repeater is not necessarily the one with the largest
RSSI value in the channels of the scan list.
RSSI
(Strong Signal
Roaming)
Once a repeater in the channels of the scan list with RSSI
more than preset RSSI threshold value is searched by RSSI
mode, the radio will lock to the current channel and pause
the strong signal auto roaming. Then it will connect with the
current repeater according to the preset Connect Check
Timer. If the connection fails after the preset Connect lime
is used up, it will restart the strong signal Auto roaming
search.
(2) RSSI Set → press the [Select]-key to display the current RSSI threshold value
→ rotate the [ENC] knob or use the [▲/▼]-keys to adjust the desired value
→ press the [OK]-key to confirm the modification → ‘Set Ok!’ pops up on the
screen and return to the previous level.
Threshold values: Maximum: - 90 dBm
Minimum: - 125 dBm
Increment: -1 dBm
Notes: The received signal strength (RSSI threshold value) is settable. If the RSSI mode
is enabled and the searched repeater RSSI value is more than the preset
threshold, the repeater's transmitting signal coverage will be automatically
recognized as good, and then the radio will suspend RSSI roaming. The
stopped repeater is not necessarily the one with the largest RSSI value in the
channels of the scan list.
