- 29 -
16.1. Adjustment Report
<P6.1.CrEP> is a group of parameters allowing you to declare variables that
are to be printed on an adjustment report printout. Each variable features
accessibility attribute: YES – print, no – do not print. Adjustment report is
automatically generated at the end of each adjustment process.
Variables list:
No. Name Description
6.1.1. CtP Performed adjustment type.
6.1.2. dAt Adjustment date.
6.1.3. tin Adjustment time.
6.1.4. Idb Serial number of the scale.
6.1.5. CdF
Difference between mass of adjustment weight that was measured
during last adjustment and mass of currently measured adjustment
weight.
6.1.6. dSh Dashed line separating printout data and signature fields.
6.1.7. SiG
An area for the signature of an operator carrying out the
adjustment.
Printouts are generated exclusively in English.
Report example:
16.2. GLP Printout
<P6.2.GLP> is a group of parameters allowing you to declare variables that are
to be printed on a weighing printout. Each variable features accessibility
attribute: YES – print, no – do not print.
