Attachment and installation
19
3
3.4 Preparation of metering slide
The AXIS 20.1 Q, AXIS 30.1 W, AXIS 30.1 Q, AXIS 40.1 W, AXIS 40.1 Q and
AXIS 50.1 W fertiliser spreader have an electronic slide control for adjusting the
spreading volume.
Figure 3.6: Preparation of the metering slide (example)
n CAUTION
Observe the position of the metering slide
The operation of the actuators by the Quantron E can damage the
metering slide if the stop levers are incorrectly positioned.
Always clamp the stop lever at the maximum scale position.
NOTICE
Observe the operating manual for the fertiliser spreader.
