Layout and function 2
10
2.4 Display
The display shows the current status information and the selection and input op-
tions for the control unit.
The most important information on the operation of the fertiliser spreader is dis-
played in the operating screen.
Description of the operating screen
7 Navigation field 4 arrow keys and one Enter key for navigation in the
menus and the input fields.
 Arrow keys for moving the cursor on the display
or to highlight an input field.
 Enter key to confirm an input.
8 Function keys F1
to F4
Selection of the functions displayed by the function
button.
9 Weighing - Trip-
counter
 Dsplay of the remaining fertiliser volume that is
still in the hopper.
 Tripcounter
 kg rest
 Metre counter
 Weigh volume
1
 Tare scales
1
10 Display display of operating screens
11 On / Off Switching the unit on/off
1. The menu item only appears on the display if the fertiliser spreader used is an AXIS W.
No. Designation Function
NOTICE
The exact representation of the operating screen depends on the actual settings
selected, see section 4.8.2:
Display config., page 68.
