Operation Quantron E 4
50
4.5.2 AUTO / MAN mode
By default you operate in AUTO mode. The control unit automatically controls the
actuators as specified by the speed signal.
Only work in manual mode if:
there is no speed signal (radar or wheel sensor not available or defective),
seed auger or seeds (fine seeds) are to be discharged.
Figure 4.24:AUTO/MAN mode menu
[1] Metering slide adjustment for manual mode
[2] Adjustment of ground speed for manual mode
[3] Selecting automatic mode
[4] Selecting automatic mode with static weighing
[5] Selecting automatic mode with automatic weighing
Automatic mode with automatic weighing (AUTO km/h + Auto kg)
The AUTO km/h + Auto kg operating mode allows for continuous weighing of
the fertiliser volume in the hopper during spreader operation. The regulation of
the flow factor is corrected at regular intervals on the basis of this information.
This optimises the metering of the fertiliser.
NOTICE
When working in manual mode you must always operate at a constant ground
speed to ensure even spreading.
NOTICE
The AUTO km/h + Auto kg menu only appears on the display if the AXIS W
fertiliser spreader has been configured in the factory.
With the AXIS W setting, the AUTO km/h + Auto kg operating mode is presel-
ected as standard at the factory.
1
4
5
3
2
