Operation Quantron E
69
4
4.8.3 Test / Diagnosis
In the Test/Diagnosis menu you can monitor the function of certain sensors/ac-
tuators.
1. Switch from the System/Test menu to the submenu Test/Diagnosis.
2. Highlight the desired function and press the enter key.
 The display shows the status of the sensors or actuators.
NOTICE
This menu serves only for information purposes.
The list of the sensors depends upon the equipment level of the machine.
Submenu Meaning Description
Slide test points Test for engaging the various
position points of the slider.
Checking the calibration
Slide Driving the left and right mete-
ring slide
Voltage Checking the operating voltage. page 70
Weighing cells Check of actuators and sensors. page 70
Drop point Engaging the drop point.
Empty message
sensors
Check
Telimat Sensor Checking the Telimat Sensors. page 70
