Several options for scaling can be selected. These are described below.
o Auto-scaling: Depending on the values to be displayed, the minimum and maximum axis value
are selected to ensure that they are optimally displayed.
o Setup 1: The following measuring position-specific axis scaling is highlighted in Setup 1
Table 9: Axis scaling in Setup 1
Measuring
position
Scaling range in mmHg
Measuring
position
Scaling range in mmHg
ICP1/2
0-50
ART
50-150
ICPT
0-50
CVP
0-20
pO2
0-60
o Setup 2: The following measuring position-specific axis scaling is highlighted in Setup 2
Table 10: Axis scaling in Setup 2
Measuring
position
Scaling range in mmHg
Measuring
position
Scaling range in mmHg
ICP1/2
0-20
ART
75-150
ICPT
0-20
CVP
0-20
pO2
0-20
o Setup 3: The following measuring position-specific axis scaling is highlighted in Setup 3
Table 11: Axis scaling in Setup 3
Measuring
position
Scaling range in mmHg
Measuring
position
Scaling range in mmHg
ICP1/2
-20 to 100
ART
50-200
ICPT
-20 to 100
CVP
0-50
pO2
0-100
o User-defined: You can specifically adjust the axis scaling for every measuring position, in the
Live Graph View.
To do this, please perform the following steps. See Figure 12.
<1> Press the axis of the particular measuring position <2>. An input window appears and
the scaling range can be adjusted with the Plus/Minus buttons<3>. Confirm the input.
