Sensor sensitivity
Characteristic curve saved in device, catheter parameters in the
EEPROM in the catheter plug
Accuracy:
± 3% of the reading or ± 2.5 mmHg – whichever is greater
Value for oxygen partial pressure < 120 mmHg
< 10% of the reading for oxygen partial pressure
120-200 mmHg
Analogue outputs Out1/2
Number of channels:
2
Switchable sizes:
Invasive pressure, oxygen partial pressure
Resolution:
< 0.5 mmHg, typically 0.23 mmHg
Output range:
- 40 ... + 400 mmHg
Accuracy after zero calibration *1:
+ 2 mmHg in 10 – 40°C environment
Output frequency:
100 Hz
Sensitivity:
5 V / V / mmHg
Recommended supply voltage:
4 – 6 VDC
Maximum supply voltage
10 Vp-p
Thermal drift
Max. 0.5 mmHg/K
Defibrillator protection
No
*1: Zero calibration of the following monitor
Analogue Rec output
Number of channels:
1
Switchable sizes:
Invasive pressure, oxygen partial pressure, temperature
Resolution:
0.1 mmHg or 0.01 °C
Output range:
- 40 ... + 400 mmHg or 15 ... 45 °C
Accuracy after zero calibration:
± 2 mmHg or ± 0.2 K in 10 – 40 °C environment
Output frequency:
Max. 100 Hz (depending on measuring position) or 1 Hz (for
temperature)
Sensitivity:
10 mV/mmHg or 150 mV/°C
Defibrillator protection
No
