CHAPTER 8
70 RCM - Sprayer and AIM Command FLEX™ II Calibration and Operation Manual
523014 .13 NCV requires message •Go to Diagnostics -> Diagnostic Trouble Codes
-> NCV Errors -> NCV Heat Map and locate
the NCV(s) that are not green. Their numerical
locations are labeled referencing the forward
travel direction, from leftmost to rightmost
NCV along the boom. Note their location for
future reference and troubleshooting as
necessary.
• Cycle power to RCM-S ECU by going to
Diagnostics -> Tests -> Reboot Product
Controller.
• Check NCV software by going to Diagnostics
-> Tests -> NCV Updates to scan and update
software on affected NCVs.
• Replace affected NCV's. Then recalibrate
NCV's by going to Diagnostics -> Tests ->
Calibrate NCVs. If necessary, check NCV
software by going to Diagnostics -> Tests ->
NCV Updates to scan and update software on
affected NCV's.
523016 .31
Inconsistent nozzle control
valve software version
523017 .31
NCV programming out of
date (NCV update)
523128 .0
High NCV temperature -
single
• May result from high ambient temperature or
running NCVs without flowing liquid. Allow
NCVs to cool.
• Replace NCV and Recalibrate NCVs by going
to Diagnostics -> Tests -> Calibrate NCVs
523129 .0
High NCV temperature -
multiple
523136 .4 NCV voltage low single • Check wiring, fuses, and connections before
the left and right cable circuit branches. When
only a few NCVs are noted, inspect nearby
NCVs, connections, pins, and cabling for
corrosion, visible damage, or pinching
between those NCVs. In some instances,
splices or wiring may be damaged
underneath cable coverings. Repair or replace
as necessary.
• Check power and ground on chassis cable
connectors. Repair or replace as necessary.
• Check power and ground at battery terminals
and connections. Repair or replace as
necessary.
• Check machine battery and charging system.
Repair or replace as necessary.
523137 .4 NCV voltage low multi
Code ID Description Recommended Actions
