Raven ISO Product Controller II User Manual

CHAPTER 1
2 ISO Product Controller II and Hawkeye Operation Manual
• Thoroughly wash hands and face after using agricultural chemicals and before eating, drinking, or
using the rest room.
• Thoroughly flush or rinse equipment used to mix, transfer, or apply chemicals with water after use
or before servicing any component of the application system.
• Follow all federal, state, and local regulations regarding the handling, use, and disposal of agricultural
chemicals, products, and containers. Triple-rinse and puncture or crush empty containers before disposing of
them properly. Contact a local environmental agency or recycling center for additional information.
ELECTRICAL SAFETY
• Always make sure that the power leads are connected to the correct polarity as marked. Reversing the lead
wires could cause severe damage to electrical components and equipment.
• Connect the power cable last.
• Disconnect the Hawkeye nozzle control system from the vehicle battery before jump-starting the vehicle.
• Disconnect the Hawkeye nozzle control system from the vehicle battery before welding any component of the
implement.
INSTRUCTIONS FOR WIRE ROUTING
The word “harness” is used to mean all electrical leads and cables, bundled and unbundled. When installing
harness, secure it at least every 30 cm (12in) to the frame. Follow existing harness as much as possible and use
these guidelines:
Harness should not contact or be attached to:
• Lines and hoses with high vibration forces or pressure spikes
• Lines and hoses carrying hot fluids beyond harness component specifications
Avoid contact with any sharp edge or abrading surfaces such as, but not limited to:
• Sheared or flame cut edges
• Edges of machined surfaces
• Fastener threads or cap screw heads
• Ends of adjustable hose clamps
• Wire exiting conduit without protection, either ends or side of conduit
• Hose and tube fittings
Routing should not allow harnesses to:
• Hang below the unit
• Have the potential to become damaged due to exposure to the exterior environment. (i.e. tree limbs, debris,
attachments)
• Be placed in areas of or in contact with machine components which develop temperatures higher than the
temperature rating of harness components
• Wiring should be protected or shielded if it needs to route near hot temperatures beyond harness component
specifications
Harnessing should not have sharp bends
CAUTION
