Raven ISO Product Controller II User Manual

CHAPTER
2
P/N 016-0171-584-H 7
CHAPTER 2 INTRODUCTION
The Hawkeye
®
Nozzle Control System is designed to provide PWM product rate and nozzle control via an ISOBUS
universal terminal (UT). Adding the Hawkeye
®
control system to an existing ISOBUS product control system will
allow a machine operator to monitor and control product application rate and pressure independently directly
from the UT without additional displays, controllers, or consoles.
This document provides information regarding the following aspects of the Hawkeye
®
nozzle control system:
• Initial Setup and Navigation
• Calibration
•Hawkeye
®
System Operation
•Hawkeye
®
Operation When Used With Direct Injection
•Updating Hawkeye
®
Components
NOTE: Prior to using the Hawkeye
®
control features with any UT display, the Hawkeye
®
Electronic Control
Unit (Product Controller II ECU) must be calibrated for the control system. Refer to Chapter 3, System
Calibration, for assistance with completing the initial calibration wizard.
This manual assumes that the required control hardware is already installed on supported equipment
and is properly connected. Contact a local Raven dealer for additional information on supported
equipment configurations.

Raven ISO Product Controller II Specifications

General

Brand	Raven
Model	ISO Product Controller II
Category	Controller
Language	English
