CHAPTER 3
16 ISO Product Controller II and Hawkeye Operation Manual
5. Enter the desired boom offset from the rear axle.
6. Touch Next to proceed to the Switch Mapping prompt if a switchbox or boom sense node is detected.
7. For each configured section, use the drop down field to select the desired switch number to assign each
configured section to a switch.
8. When all section switches are configured for the desired operation, select the Next button to proceed to the
Valve Calibration prompt.
VALVE CALIBRATION
1. Select the appropriate valve type. Press next to proceed to Pressure Transducer Calibration.
PRESSURE TRANSDUCER CALIBRATION
1. Select the Transducer Type. Available options are 0-250 PSI, 0-150 PSI. If a custom transducer is being used,
select one of the two options available in the wizard. After the calibration wizard has completed, navigate to
the Advanced Pressure Calibration Menu and select Custom. Follow the instructions for custom transducer
calibration.
2. Press Next. If a sparge transducer is detected the Sparge Pressure Calibration prompt will appear. If a sparge
transducer is not detected, the Meter Cal prompt will appear.
3. If a secondary Sparge Pressure Transducer is detected, select the transducer type and press the Next button to
proceed to the meter cal prompt.
METER CAL AND UNITS
1. Select the Meter Cal field and enter the calibration value for the flow meter used to monitor the Hawkeye
®
system product flow.
2. Select the units field and select the units used by the flow meter to monitor flow.
NOTE: Raven flow meters use a meter cal in pulses per 10 gallons [37.9 L]. Other flow meters may use
different meter cal rates.
3. Select the Next button to proceed to complete calibration.
FUNCTIONAL INSPECTION
Refer to the following sections for assistance with validating that the Hawkeye
®
nozzle control system has been
installed properly:
NOZZLE CONTROL VALVE FUNCTION
To verify that the Hawkeye
®
nozzle control system is functioning properly after installation:
1. Flush the main product tank and boom plumbing with clean water, and verify the tank contains at least 100
gallons [379 L] of clean water.
2. Park the equipment in an area with enough space to unfold the booms and allows for visual inspection of the
spray pattern from a moderate distance (e.g. 20 ft [6.1 m]).
3. Set the Hawkeye
®
nozzle control system to manual mode, and set both the pump PWM and nozzle PWM to
50%.For Applicators, adjust the nozzle PWM valve up or down with the bump keys. The pressure gauge must
be toggled to access the nozzle PWM.
4. If necessary, open the tank valve.
5. If present, turn on the machine’s switch then press the on-screen pump soft key to engage the pump.
