Raven ISO Product Controller II User Manual

System Calibration: Sidekick Pro ICD Injection Initial Setup and Calibration 19
SYSTEM CALIBRATION
FIGURE 4. Equipment Settings
6. Select the Injection Wizard.
7. Locate the Sidekick Pro ICD Product Controller II ECU serial number. The serial number is typically located on
the front or top of the direct injection pump.
8. Assign the desired Sidekick Pro ICD Product Controller II ECU to the desired product channel.
FIGURE 5. Injection Wizard Serial Number Assignment
9. Press the Next softkey.
FIGURE 6. Next Screen
10. Set the desired Target Rate for each Sidekick Pro ICD Product Controller II ECU.
