CHAPTER 4

24 ISO Product Controller II and Hawkeye Operation Manual

FLOWMETER CAL

Flowmeter Cal shows the current calibration number for the installed flowmeter.

PRESSURE SENSOR

Pressure Sensor shows the current allowable pressure range for the installed pressure sensor.

BOOM OFFSET

Boom Offset displays the set offset distance from the boom to the rear axle.

TOTAL NOZZLE COUNT DISPLAY

The number of nozzles detected on the Hawkeye

nozzle control bus during the calibration wizard will be

displayed in this field. If the nozzle count does not match the expected number of nozzles connected to the

system, troubleshoot the nozzle control valve bus and restart the calibration wizard. Refer to Chapter 8,

Troubleshooting, for additional troubleshooting assistance.

VALVE TYPE

Displays the valve type selected during machine configuration.

FENCE ROWS DISPLAY

Fence rows are only available if calibrated as a sprayer. If fence rows are enabled, the operator may use the left and

right fence row switches to toggle fence row valves on or off during field applications. Restart the calibration

wizard to change this setting.

NOTE: To allow the system to control fence row valves, the valves must be connected to the boom cable

connections. Refer to the Hawkeye

installation manual provided with the nozzle control kit for

additional assistance with the system installation and connection.

APPLICATION TYPE

Displays the Application Type selected during machine configuration.

NOZZLE SPACING DISPLAY

The nozzle spacing measurement set during the machine configuration is displayed in this field. This value,

multiplied by the total nozzle count should equal the total width value.

NOTE: If calibrated as an Applicator, the end NCV’s are each considered half a row. The row spacing value

multiplied by the number of crop rows should equal the total width value.
