APPENDIX A
76 ISO Product Controller II and Hawkeye Operation Manual
FOR EXAMPLE:
Under-application with diagonal banding may be observed if the following modification to the initial example
are made:
• Using 80° fan spray tips at a height of 21 inches [53.3 cm].
• Boom pressure is too low resulting in the nozzle tip not being able to achieve full spray pattern.
NOTE: Refer to Recommendations for Hawkeye Nozzle Control Operation section on page 73 and recall the
recommended spray height for 80° spray tips. Refer to Tip Selection and Application Speed Guide
section on page 77 for boom and spray tip pressure recommendations.
FIGURE 3. Conditions Resulting in Under Application and Diagonal Banding
Tip Spacing
20 inch [50.8
cm]
80°
Spray Tip
Height
Direction of
Travel
21 inch
[53.3 cm]
Alternating Spray Pattern
V
e
h
i
c
l
e
T
r
a
v
e
l
1
5
M
P
H
[
2
4
.
1
k
m
/
h
]
Alternating Spray Tip Pattern
Coverage View from Above
Diagonal Banding
