Raven ISO Product Controller II User Manual

: Tip Selection and Application Speed Guide 79
STANDARD STYLE NOZZLE BODIES
TABLE 3. Speed Table for Standard (Straight) Style Nozzle Bodies (Imperial)
Tip
Size
Boom
Pressure
(PSI)
Speed Range (MPH)
3 GPA 5 GPA 8 GPA 10 GPA 15 GPA 20 GPA
015
20.0
5.4 10.6 3.2 6.3 2.0 4.0 1.6 3.2 1.1 2.1 0.8 1.6
30.0
6.0 12.9 3.6 7.8 2.2 4.8 1.8 3.9 1.2 2.6 0.9 1.9
40.0
6.5 14.9 3.9 9.0 2.4 5.6 1.9 4.5 1.3 3.0 1.0 2.2
50.0
6.9 16.7 4.1 10.0 2.6 6.3 2.1 5.0 1.4 3.3 1.0 2.5
60.0
733 18.3 4.4 11.0 2.7 6.9 2.2 5.5 1.5 3.7 1.1 2.7
02
20.0
6.2 13.7 3.7 8.2 2.3 5.1 1.8 4.1 1.2 2.7 0.9 2.1
30.0
6.9 16.8 4.2 10.1 2.6 6.3 2.1 5.0 1.4 3.4 1.0 2.5
40.0
7.6 19.4 4.5 11.7 2.8 7.3 2.3 5.8 1.5 3.9 1.1 2.9
50.0
8.2 21.7 4.9 13.0 3.1 8.1 2.4 6.5 1.6 4.3 1.2 3.3
60.0
8.7 23.8 5.2 14.3 3.3 8.9 2.6 7.1 1.7 4.8 1.3 3.6
025
20.0
7.1 17.4 4.2 10.4 2.7 6.5 2.1 5.2 1.4 3.5 1.1 2.6
30.0
8.0 21.3 4.8 12.8 3.0 8.0 2.4 6.4 1.6 4.3 1.2 3.2
40.0
8.9 24.6 5.3 14.8 3.3 9.2 2.7 7.4 1.8 4.9 1.3 3.7
50.0
9.6 27.5 5.8 16.5 3.6 10.3 2.9 8.2 1.9 5.5 1.4 4.1
60.0
10.3 30.1 6.2 18.1 3.8 11.3 3.1 9.0 2.1 6.0 1.5 4.5
03
20.0
7.9 20.6 4.7 12.4 3.0 7.7 2.4 6.2 1.6 4.1 1.2 3.1
30.0
9.0 25.3 5.4 15.2 3.4 9.5 2.7 7.6 1.8 5.1 1.4 3.8
40.0
10.0 29.2 6.0 17.5 3.8 11.0 3.0 8.8 2.0 5.8 1.5 4.4
50.0
10.9 32.6 635 19.6 4.1 12.2 3.3 9.8 2.2 6.5 1.6 4.9
60.0
11.7 35.8 7.0 21.5 4.4 13.4 3.5 10.7 2.3 7.2 1.7 5.4
04
20.0
9.5 27.2 5.7 16.3 3.6 10.2 2.9 8.2 1.9 5.4 1.4 4.1
30.0
11.1 33.3 6.6 20.0 4.1 12.5 3.3 10.0 2.2 6.7 1.7 5.0
40.0
12.3 38.5 7.4 23.1 4.6 14.4 3.7 11.5 2.5 7.7 1.9 5.8
50.0
13.5 43.0 8.1 25.8 5.1 16.1 4.0 12.9 2.7 8.6 2.0 6.5
60.0
14.5 47.1 8.7 28.3 5.4 17.7 4.4 14.1 2.9 9.4 2.2 7.1
05
20.0
11.1 33.5 6.7 20.1 4.2 12.6 3.3 10.1 2.2 6.7 1.7 5.0
30.0
13.0 41.0 7.8 24.6 4.9 15.4 3.9 12.3 2.6 8.2 1.9 6.2
40.0
14.6 47.4 8.7 28.4 5.5 17.8 4.4 14.2 2.9 9.5 2.2 7.1
50.0
16.0 53.0 9.6 31.8 6.0 19.9 4.8 15.9 3.2 10.6 2.4 7.9
60.0
17.2 58.0 10.3 34.8 6.5 21.8 5.2 17.4 3.4 11.6 2.6 8.7
06
20.0
12.6 39.5 7.6 23.7 4.7 14.8 3.8 11.9 2.5 7.9 1.9 5.9
30.0
14.7 48.4 8.9 29.0 5.6 18.1 4.4 14.5 3.0 9.7 2.2 7.3
40.0
16.7 55.9 10.0 33.5 6.3 21.0 5.0 16.8 3.3 11.2 2.5 8.4
50.0
18.3 62.5 11.0 37.5 6.9 23.4 5.5 18.7 3.7 12.5 2.8 9.4
60.0
19.8 68.4 11.9 41.1 7.4 25.7 5.9 20.5 4.0 13.7 3.0 10.3
08
20.0
15.4 50.6 9.2 30.4 5.8 19.0 4.6 15.2 3.1 10.1 2.3 7.6
30.0
18.2 62.0 10.9 37.2 6.8 23.2 5.5 18.6 3.6 12.4 2.7 9.3
40.0
20.6 71.6 12.4 42.9 7.7 26.8 6.2 21.5 4.1 14.3 3.1 10.7
50.0
22.7 80.0 13.6 48.0 8.5 30.0 6.8 24.0 4.5 16.0 3.4 12.0
60.0
24.6 87.6 14.8 52.6 9.2 32.9 7.4 26.3 4.9 17.5 3.7 13.1
10
30.0
21.2 73.7 12.7 44.2 7.9 27.7 6.3 22.1 4.2 14.7 3.2 11.1
40.0
24.0 85.1 14.4 51.1 9.0 31.9 7.2 25.5 4.8 17.0 3.6 12.8
50.0
26.5 95.2 15.9 57.1 9.9 35.7 8.0 28.6 5.3 19.0 4.0 14.3
60.0
26.8 104.3 17.3 62.6 10.8 39.1 8.6 31.3 5.8 20.9 4.3 15.6
