Raymarine e7 Installation Instructions

2.1Handbookinformation
Thishandbookcontainsimportantinformationregardingthee7/
e7Dmultifunctiondisplay.
Thehandbookisforusewiththefollowingmodels:
•e7Multifunctiondisplay.
•e7DMultifunctiondisplay.
e7/e7Dhandbooks
Thefollowinghandbooksareapplicabletothee7/e7Dmultifunction
display:
AlldocumentsareavailabletodownloadasPDFsfrom
www.raymarine.com
e7/e7Dhandbooks
DescriptionPartnumber
Installationinstructions87136
Userreference
81332
Quickreference
86143
Additionalhandbooks
DescriptionPartnumber
SeaTalk
ng
referencemanual
81300
2.2Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem
2
Obtainallrequiredequipmentandtools
3
Siteallequipment
4Routeallcables.
5
Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7
Secureallequipmentinplace.
8Powerontestthesystem.
14
e7/e7D—Installationinstructions

Raymarine e7 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX6
GPS	Integrated 50 channel GPS
Networking	NMEA 2000, Wi-Fi, Bluetooth
Cartography	Navionics, C-MAP
Operating Temperature	-25°C to +55°C (-13°F to +131°F)
Storage Temperature	-30°C to +70°C (-22°F to +158°F)
Weight	1.25 kg (2.75 lbs)
