Raymarine e7 - NMEA 0183 Connection

3.10NMEA0183connection
6
D12 16 9-1
1 2 3 4 5
11
7 8 9 10
12
NMEA DEVICE
4800 / 9600 / 38400 baud
NMEA DEVICE
4800 / 9600 / 38400 baud
NMEA0183devicesareconnectedusingthesuppliedpowerand
datacable.
Thedisplayhas2NMEA0183ports:
•Port1:Inputandoutput,4800,9600or38400baudrate.
•Port2:Inputonly,4800,9600or38400baudrate.
Note:Thebaudrateyouwanttouseforeachportinputmustbe
speciedintheSystemSettingsmenu(Homescreen:>Set-up
>SystemSettings>NMEASet-up>NMEAInputPort).
Note:ForPort1,boththeinputandoutputcommunicateatthe
samebaudrate.Forexample,ifyouhaveoneNMEA0183
deviceconnectedtothedisplay’sPort1INPUT ,andanother
NMEA0183deviceconnectedtothedisplay’sPort1OUTPUT,
bothNMEAdevicesmustbeusingthesamebaudrate.
Youcanconnectupto4NMEA0183devicestothedisplay’sNMEA
0183OUTPUT(Port1).Youcanconnectatotalof2NMEA0183
devicestothedisplay’sNMEA0183INPUT(Port2).
56e7/e7D—Installationinstructions
