3.12Videoconnection
Avideodevicecanbeconnectedtothemultifunctiondisplayusing
thevideoconnectoronthepoweranddatacable.
Examplesofvideosourcesthatyoucanconnecttothedisplay
include:
•Videocamera.
•Thermalcamera.
•DVDplayer.
•Smartphone(typicallyrequiresadockingstationfeaturingavideo
output).
•Portabledigitalvideoplayer.
D12 17 8-1
1
2
4
3
1.Multifunctiondisplay.
2.Poweranddatacable.
3.Videoconnector.
4.Videosource—forexample,videocamera.
Videospecication
SignaltypeComposite
Format
PALorNTSC
ConnectortypeBNC(female)
60e7/e7D—Installationinstructions
