3.4Networkconnections
YoucanconnectanumberofdigitaldevicestoyourmultifunctiondisplayusingtheNetworkconnectorattherearoftheunit.
Atypicalnetworkofdigitaldevicesmayinclude:
•Upto6e7/e7Dmultifunctiondisplays.
•SeaT alk
hs
digitaldevicessuchasaDigitalSounderModule(DSM)
orradarscanner.
•Thermalcamera.
Note:Anetworkcontainingmorethanasingleconnection
requiresaRaymarinenetworkswitch.Thisisahubusedfor
connectingmultipledevices.
TypicalSeaTalk
hs
network
D12 14 6-1
21 2 3 4
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
1.Raymarinenetworkswitch.
2.Multifunctiondisplay.
3.Digitalradarscanner.
4.Thermalcamera.
