5.5Sonarcheck
Warning:Sonaroperation
•NEVERoperatethesounderwiththeboatoutof
thewater.
•NEVERtouchthetransducerfacewhenthesounder
ispoweredon.
•SWITCHOFFthesounderifdiversarelikelytobe
within7.6m(25ft)ofthetransducer.
SonartransducerandDSMselection
YoumustdesignatethesonartransducerandDigitalSounder
Module(DSM)thatyouwanttouse.
DigitalSounderModule(DSM)selection
•“D”variantmodelsarettedwithaninternalsonarDSM.
•AllmodelsallowyoutoconnectacompatibleexternalDSMunit.
•IfanexternalDSMunitisconnectedtoa“D”variantmodelanda
powersupplytheinternalDSMisdisabled.
•T ousetheinternalDSMon“D”variantmodelsthatarealso
connectedtoanexternalDSM,disconnectthenetworkcablefrom
theexternalDSMunitandusetheSounderSet-Upmenuinthe
shnderapplicationtoenabletheinternalDSM.
Transducerselection
•“D”variantmodelsallowthedirectconnectionofEITHERa
RaymarineORaMinnKotasonartransducer.
•AllmodelsallowtheconnectionofaRaymarinesonartransducer
viaacompatibleexternalDSMunit.
•ForallmodelsusetheTransducerSet-Upmenuintheshnder
applicationtospecifythesonartransduceryouwanttouse.
SelectingthesonarDSM
ApplicableonlytomultifunctiondisplayswithaninternalDSM.
Withtheshnderapplicationdisplayed:
1.PresstheMenubutton.
2.SelectSet-Up.
3.SelectSounderSet-Up.
4.SelectInternalSounder.
5.SelecttheOnoption.
Note:TheInternalSoundermenuitemisdisabledifanexternal
DSMunitisconnectedtothemultifunctiondisplayandapower
supply.DisconnectthenetworkcablefromtheexternalDSMunit
toenablethedisplay’sinternalDSMoption.
Selectingthesonartransducer
Withtheshnderapplicationdisplayed:
1.PresstheMenubutton.
2.SelectSet-Up.
3.SelectTransducerSet-Up.
4.SelecttheSelectTransducermenuitem.
5.Selectthetransduceryouwanttouse.
Checkingthesonar
Sonarchecksaremadeusingtheshnderapplication.
Systemchecks
83
