Productdimensions
A
C
D
D12 18 5-1
B
E
A
233mm(9.17in.)
B
145mm(5.71in.)
C64mm(2.52in.)
D
150mm(5.9in.)
E
180mm(7.09in.)
4.2Removingtherearbezel
Youmustremovetherearbezelbeforeush-mountingthedisplay.
1.Removethefrontbezel.Refertotheseparateinstructions
providedforthatprocedure.
D12 18 4-1
2
3
1
2.Removethescrewsthatsecurethebezeltothedisplay.
3.Carefullyremovethebezelfromtherearofthedisplay,pulling
thebezelgentlyalongthe:
i.Outeredges-workfromthesidesupwardsandthenalong
thetopedge,ensuringthattheclipsarefullyreleasedfrom
thedisplay.
ii.Inneredges-ensurethatthebezeliscompletelyremoved
fromthedisplay.
68e7/e7DInstallationinstructions
