Raymarine e7 - Initial Power on Test

5.1Initialpowerontest
Touchscreenoverview
Thetouchscreenprovidesaquickwayofperformingmanycommon
functions.
Someofthefunctionsyoucanoperatewiththetouchscreeninclude:
•Accessingapplications.
•Addingandeditingapplicationspages.
•Placingandeditingwaypoints.
•Buildingroutes.
•Panningthechartdisplay.
•Placingandmovingthecursor.
Note:Raymarinestronglyrecommendsthatyoufamiliarize
yourselfwithtouchoperationswhileyourvesselisanchored
ormoored.Youmayndithelpfultousethesimulatormode
(accessiblefromHomescreen>Set-up>SystemSettings)
inthesesituations.
Controls
D12 17 9-1
2
4
5
6
7
3
1
1.Touchscreen—youcantouchthescreentooperatemany
commonfunctions,includingallmenuoperations.
2.Menu—accessesmenus.Pressagaintoclosemenus.
3.UniControl—providesajoystickandrotarycontrolandanOK
buttonforusingmenusandapplications.
4.Back—presstoreturntoapreviousmenuordialoglevel.
5.WPTS/MOB—pressandreleasetoaccessthewaypoint
options.Pressagaintoplaceawaypoint.Pressandholdto
placeaManOverboard(MOB)markeratyourcurrentposition.
6.Power—pressoncetoswitchtheunitON.Oncepoweredon,
pressthePowerbuttonagaintoadjustthebrightness,access
thepowercontrolsforexternaldevices,andaccesstheautopilot
controls.PressandholdtoswitchtheunitOFF.
7.Chartcardslots—openthecarddoortoinsertorremove
MicroSDcards.Thereare2cardslots(labelled1and2),used
forelectronicchartsandarchivingwaypoint,routeandtrack
data.
76e7/e7D—Installationinstructions
