Raymarine e7 Installation Instructions

•BMEAcodeofpractice
•NMEA0400
Powercable
Thedisplayissuppliedwithacombinedpoweranddatamulticable,
thiscanbeextendedifrequired.
Powercablesupplied
CablePartnumberNotes
1.0m(3.3ft)Powerand
datacable
R62379
Suppliedwithunit.
Cableextension
Thefollowingrestrictionsapplytoanyextensiontothepowercable:
•Cablemustbeofasuitablegaugeforthecircuitload.
•Eachunitshouldhaveitsowndedicatedpowercablewiredback
tothedistributionpanel.
Totallength(max)SupplyvoltageCablegauge(AWG)
0–5m(0–16.4ft)
12V18
5–10m(16.4–32.8ft)
12V14
10–15m(32.8–49.2ft)
12V12
15–20m(49.2–65.5ft)
12V12
Note:Thesedistancesarefora2wirepowercablerunfromthebatteryto
thedisplay(approximatelythedistancefromthebatterytothedisplay).To
calculatetheroundtriplength,doublethegurestatedhere.
Breakers,fusesandcircuitprotection
Thepowercableincludesanin-linefuse.Itisrecommendedthat
youtanadditionalthermalbreakerorfuseatthedistributionpanel.
DisplayFuseratingThermalbreakerrating
•e7/e7D7Ain-linefusetted
withinpowercable.
5A(ifonlyconnecting
onedevice)
Note:Thesuitablefuseratingforthethermalbreakeris
dependentonthenumberofdevicesyouareconnecting.Ifin
doubtconsultanauthorisedRaymarinedealer.
Cablesandconnections37

Raymarine e7 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX6
GPS	Integrated 50 channel GPS
Networking	NMEA 2000, Wi-Fi, Bluetooth
Cartography	Navionics, C-MAP
Operating Temperature	-25°C to +55°C (-13°F to +131°F)
Storage Temperature	-30°C to +70°C (-22°F to +158°F)
Weight	1.25 kg (2.75 lbs)
