Raymarine e7 Installation Instructions

TypicalSeaTalk
ng
system
SMARTPILOT
D12 17 6-1
12 V / 24 V dc 12 V dc + Data
SeaTalk
ng
1 2
6
9 10
8 8
5
7
3
4
1.SeaTalk
ng
instrument—forexample,i70.
2.SeaTalk
ng
pilotcontrolhead—forexample,p70.
3.Transducerpod.
4.Windtransducer.
5.SeaTalk
ng
multifunctiondisplay.
6.Powersupply.
7.SeaTalk
ng
coursecomputer—forexample,SPX-30.
8.Transducerpod.
9.Depthtransducer.
10.Speedtransducer.
SeaTalk
ng
powerrequirements
TheSeaTalk
ng
busrequiresa12Vpowersupply.
Powermaybeprovidedfrom:
•Raymarineequipmentwitharegulated12Vpowersupply(for
example,aSmartPilotSPXcoursecomputer);or:
•Othersuitable12Vpowersupply.
Note:SeaT alk
ng
doesNOTsupplypowertomultifunctiondisplays
andotherequipmentwithadedicatedpowersupplyinput.
SeaTalk
ng
cablingcomponents
SeaTalk
ng
cablingcomponentsandtheirpurposes.
52e7/e7D—Installationinstructions

Raymarine e7 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX6
GPS	Integrated 50 channel GPS
Networking	NMEA 2000, Wi-Fi, Bluetooth
Cartography	Navionics, C-MAP
Operating Temperature	-25°C to +55°C (-13°F to +131°F)
Storage Temperature	-30°C to +70°C (-22°F to +158°F)
Weight	1.25 kg (2.75 lbs)
