Configurations
16
102-127108955 V1.1 73/ 102
CONTROL UNIT
0 V 24 V ‘Continuously open’
24 V 0 V ‘Automatic’
24 V 24 V ‘Manual mode’
→ 3-position (OFF-A) Operating modes:
Automatic; OFF; Continuously open
→ 3-position* (OFF-M) Operating modes:
Manual; OFF; Continuously open
→ 3-position* (VRR-A) Operating modes:
Automatic; Locked; Continuously open
→ 3-position* (VRR-M) Operating modes:
Manual; Locked; Continuously open
NOTICE
* The function does not correspond to the symbols of the three-position BDI ro-
cker switch of the DFA 127.
→ BDE-D Settings for control unit with display.
▪ All parameters for the BDE-D are saved in the STG.
NOTICE
Some parameter modifications are only registered by the BDE-D after a restart of
the controller.
→ Language Range of languages for text display on the BDE-D.
At the moment, the languages GERMAN, FRENCH, ENG-
LISH, ENGLISH US, ITALIANO, ESPANOL, NEDERLANDS,
DANISH, SLOVENSCINA, POLSKI, MAGYAR and CZECH
are available.
▪ Older BDE-D hardware offers a limited range of lan-
guages due to its reduced memory.
→ Keyboard Layout of the film and function of the keys.
→ Normal X Standard layout
→ OFF-Mode Layout for the USA. Instead of the operating mode
‘Locked’
the ‘locked’ key enables the operating mode
OFF
. The door
goes into
‘Manual mode’
and can then be e.g. locked manu-
ally.
More information in the chapter Electronic Control Unit BDE-D
(option)
→ Contrast BDE 1 20 Contrast of the display screen for 1st BDE-D.
0 = low contrast, display is faintly visible
40 = high contrast, possible streaking
