Configurations
16
102-127108955 V1.1 72/ 102
→ Active sensors The sensors for tripping or safety are connected so that their
behaviour can be influenced in ‘Manual mode’.
→ Disabled X No sensor enabled
→ SIS disabled All sensors excluding SIS enabled
→ SIS enabled All sensors including SIS enabled
→ SIS enabled AUTO SIS is only effective upon closing when the door has been
opened automatically.
NOTICE
For the correct operation of “Manual mode with active sensors” the correspond-
ing parameters must be set and the BDE-D or the toggle switch must be set to
‘Manual’ !
The door can be passed by non-disabled people as a normal manual door; dis-
abled persons may trigger an automatic opening of the door by remote control.
Menu: Manual mode / Active sensors / SIS disabled or SIS enabled
Do not enable ‘Manual mode’ with assisted closure!
→ Closing speed 20 Variable closing speed that can be situation-influenced.
0 = lowest speed
40 = highest speed
▪ The maximum reachable speed depends on the
spring tension set.
▪ Existing electric door openers must definitely engage.
CONTROL UNIT
→ BDE-M Selection of the mechanical control unit.
▪ Various functions can be assigned to the side-
mounted BDI 3-position rocker switch.
▪ The BDE-M can only be connected to STG 127 via
the option BDI-M.
▪ Not more than one BDE-M may be connected at a
time.
▪ BDE-D and BDE-M can be operated in parallel, the
operating mode being given priority.
‘Locked’
.
→ 3-position (AUTO) X Operating modes:
Manual; Automatic; Continuously open
▪ Function corresponds to the symbols of the three-
position BDI rocker switch on the side cover of the
DFA 127.
Setting for the BDE-M
▪ Appropriate setting for the time switch input (e.g.
SURV
)
BDE2 BDE1 Operating mode
→ 4-position
2)
0 V 0 V ‘Locked’
