RED DSMC OPERATION GUIDE: EPIC/SCARLET
COPYRIGHT © 2015 RED.COM, INC 955-0020_V6.0, REV-J | 17
DSMC SIDE SSD MODULE CONTROLS
# CONTROL DESCRIPTION
1 User Key 1 Programmable key
User Key 1 + 2 Press: Eject Media
2 REC button Programmable key
Full Press: Record Toggle
Half Press: AF Start
3 User Key 2 Programmable key
User Key 1 + 2 Press: Eject Media
REAR SSD MODULE
The Rear SSD Module secures to the back of a Module Adaptor or a +1 Adaptor Module to serve as a rear
location for recording to a REDMAG 1.8" SSD.
For more information, see the DSMC Media Operation Guide, available at www.red.com/downloads.
Rear SSD Module

Table of Contents

Other manuals for RED Epic

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the RED Epic and is the answer not in the manual?

RED Epic Specifications

General IconGeneral
SensorMysterium-X
Resolution5120 x 2700 (5K)
Lens MountPL Mount
Frame Rates1-120 fps
Dynamic Range13.5 stops
Recording FormatREDCODE RAW
MediaREDMAG (SSD)
Weight5 lbs (2.3 kg) body only
Sensor Size27.7 mm x 14.6 mm
Operating Temperature32°F to 104°F (0°C to 40°C)
