RED DSMC OPERATION GUIDE: EPIC/SCARLET

955-0020_V6.0, REV-J | 200

This appendix provides pinout information for the input/output connectors on the RED

BRAIN

NOTE: When connecting a cable to a connector, align the key and red marker on the cable connector with the

corresponding key and marker on the device connection.

NOTE: Connector diagram images are for reference only. Diagrams are not to scale.

3 4 5 6 7 8 9

DSMC Connectors

INPUT/OUTPUT

CONNECTORS
