RED DSMC OPERATION GUIDE: EPIC/SCARLET

# CONNECTOR CONNECTOR TYPE FOR MORE INFORMATION, GO TO...

1 REDMOTE Dock 8-point POGO “REDMOTE Operation” on page 147

2 Module Power SEARAY “Power Inputs” on page 34

3 HD-SDI BNC “3G-SDI (HD-SDI) Out” on page 201

4 HDMI HDMI “HDMI Out” on page 202

5 Headphone Jack 3.5mm stereo “Headphone” on page 206

6 SYNC 4-pin 00B LEMO

“SYNC (Video Sync In)” on page 202

7 CTRL 4-pin 00B LEMO “CTRL (RS232 Control)” on page 204

8 GIG-E 9-pin 0B LEMO “DC IN (Power Input)” on page 207

9 DC IN 6-pin 1B LEMO “DC IN (Power Input)” on page 207

N/A MIC-1, MIC-2 (Front) 3.5 mm stereo “SSD Module Connectors” on page 207

RECORD/MONITOR OUT PORTS

3G-SDI (HD-SDI) OUT

A standard 75 ohm BNC connector provides the following output:

 Broadcast specification 3G-SDI (HD-SDI) video output (default mode is Clean)

 Two (2) channels of embedded audio

 Time of Day and Edge timecode

 Record Tally flag

 Clip name information (as SMPTE RP-188 VITC2 HANC metadata)

For more information, go to “Monitor” on page 72.

The 3G-SDI (HD-SDI) output provides the formats described in the table below:

3G-SDI (HD-SDI) OUTPUT FORMATS

VIDEO FEED

FREQUENCY (HZ)

SMPTE STANDARD

720p 23.98, 24.00, 25.00, 29.97, 30.00, 50.00, 59.94 SMPTE ST 292-1 (1.485 Gbps)

1080p 10-bit 4:2:2 23.98, 24.00, 25.00, 29.97, 30.00 SMPTE ST 292 (1.485 Gbps)

1080p 10-bit 4:2:2 50.00, 59.94, 60.00 3G-SDI

SMPTE ST 424 (2.970 Gbps)

SMPTE ST 425 (2.970 Gbps)

1. Ensure you select a frequency supported by your monitor.

2. The output is progressive scan (p); it does not support progressive segmented frame (PsF) or interlaced (i) scan formats.

3. The frequency options depend on project time base. If you have a non-drop frame project time base (such as 24.00), you can select

only non-drop frame frequencies. If you have a drop frame project time base (such as 23.98), you can select only drop frame frequencies.

75 OHM BNC CONNECTOR

PIN SIGNAL DESCRIPTION DIRECTION

Center 3G-SDI SMPTE ST 424 Out

Shield/Screen GROUND Camera ground N/A
