RED DSMC OPERATION GUIDE: EPIC/SCARLET
COPYRIGHT © 2015 RED.COM, INC 955-0020_V6.0, REV-J | 187
EPIC MYSTERIUM-X
EPIC MYSTERIUM-X TECHNICAL SPECIFICATIONS
SPECIFICATION DESCRIPTION
Sensor 14 megapixel MYSTERIUM-X
®
sensor
Pixel Array 5120 (h) x 2700 (v)
S/N Ratio 66 dB
Dynamic Range 13.5 stops, up to 18 stops with HDRx
Max Image Area 5120 (h) x 2700 (v)
Lens Coverage 27.7mm (h) x 14.6mm (v) x 31.4 mm (d)
Max Depth of Field Equivalent to S35mm (Motion)/APS-H (Still) lenses
Equivalent to 16mm (Motion) lens in 2K RAW
Acquisition Formats Go to “EPIC MYSTERIUM-X and SCARLET MYSTERIUM-X Formats” on page
95 for a full list
Project Frame Rates 23.98, 24, 25, 29.97, 47.96, 48, 50, 59.94 FPS, all resolutions
Delivery Formats 4K : DPX, TIFF, OpenEXR (.RED via RRencode Plugin)
2K : DPX, TIFF, OpenEXR (.RED via RRencode Plugin)
1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG
Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264,.MP4
Program Output 3G-SDI (HD-SDI) Clean Feed
1080p RGB or 4:2:2, 720p 4:2:2
SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio
Monitor Output
1
3G-SDI (HD-SDI) and HDMI with Frame Guides and Lookaround
1080p, 720p, 480p
1
: RGB or 4:2:2
SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio
Digital Media REDMAG 1.8" SSD: 48GB, 64GB, 128GB, 256GB, 512GB
RED MINI-MAG: 120GB, 240GB, 512GB, 1TB
REDCODE To see all of the maximum available REDCODE values, see the DSMC Media
Operation Guide at www.red.com/downloads
Audio 2 channel, uncompressed, 24 bit, 48KHz
Optional 4 channel, and AES/EBU digital audio
Remote Control REDLINK Wireless, Ethernet, RS232, GPI Trigger
Weight 5 lbs (body only)
Construction Aluminum Alloy
Operating Temperature Range 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature Range –20˚C to 50˚C (–4˚F to 122˚F)
1. 480p is available for HDMI only.
