RED DSMC OPERATION GUIDE: EPIC/SCARLET
COPYRIGHT © 2015 RED.COM, INC 955-0020_V6.0, REV-J | 185
SCARLET DRAGON
SCARLET DRAGON TECHNICAL SPECIFICATIONS
SPECIFICATION DESCRIPTION
Sensor 19 megapixel RED DRAGON sensor
Pixel Array 6144 (h) x 3160 (v)
S/N Ratio 80 dB
Dynamic Range 16.5+ stops
Max Image Area 6144 (h) x 3160 (v)
Lens Coverage 30.7mm (h) x 15.8mm (v) x 34.5 mm (d)
Max Depth of Field Equivalent to S35mm (Motion)/APS-H (Still) lenses
Acquisition Formats
1
6K RAW (Full Frame, 6:5)
5K RAW (Full Frame, 2:1, WS, HD, 6:5)
4K RAW (Full Frame, 2:1, WS, HD, 6:5)
3K RAW (Full Frame, 2:1, WS, HD, 6:5)
2K RAW (Full Frame, 2:1, WS, HD, 6:5)
Project Frame Rates 23.98, 24, 25, 29.97, 47.96, 48, 50, 59.94 FPS, all resolutions
Delivery Formats 4K: DPX, TIFF, OpenEXR (.RED via RRencode Plugin)
2K: DPX, TIFF, OpenEXR (.RED via RRencode Plugin)
1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG
Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264,.MP4
Program Output 3G-SDI (HD-SDI) Clean Feed
1080p RGB or 4:2:2, 720p 4:2:2
SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio
Monitor Output
2
3G-SDI (HD-SDI) and HDMI with Frame Guides and Lookaround
1080p, 720p, 480p
2
: RGB or 4:2:2
SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio
Digital Media REDMAG 1.8" SSD: 48GB, 64GB, 128GB, 240GB, 256GB, 512GB
RED MINI-MAG: 120GB, 240GB, 512GB, 1TB
Maximum Frames
Per Second (FPS)
3
6K FF: 12 FPS (in Burst mode)
5K FF: 48 FPS
4K FF: 60 FPS
3K FF: 80 FPS
2K FF: 120 FPS
5K WS: 60 FPS
4K WS: 75 FPS
3K WS: 100 FPS
2K WS: 150 FPS
