RED Epic User Manual

COPYRIGHT © 2015 RED.COM, INC
RED DSMC OPERATION GUIDE: EPIC/SCARLET
955-0020_V6.0, REV-J | 220
DEFAULT KEY FUNCTIONS
ITEM KEY FUNCTION
RED
Switchblade-M User A Press AF Mode: Cycle
User B Press WB: Auto Calc
User C Press Magnify: Toggle
User D Press Exposure Check: Toggle
User A+D Press SM: Toggle Key Lock
Nav Menu Press Navigation: Menu
Nav North Press Navigation: Up
Nav South Press Navigation: Down
Nav East Press Navigation: Right
Nav West Press Navigation: Left
Nav Enter Press Navigation: Select
Rotary Front CW Navigation: CW
Rotary Front CCW Navigation: CCW
REDMOTE
®
User A Press AF Mode: Cycle
User B Press WB: Auto Calc
User C Press Magnify: Toggle
User D Press Exposure Check: Toggle
Still Select Focus Mode: Still
Movie Select Focus Mode: Motion
Nav Menu Press Navigation: Menu
Nav North Press Navigation: Up
Nav South Press Navigation: Down
Nav East Press Navigation: Right
Nav West Press Navigation: Left
Nav Enter Press Navigation: Select
Rotary Front CW Navigation: CW
Rotary Front CCW Navigation: CCW
Record Full Press Record: Toggle/Multi-Shot Start
Record Full Release Record: Multi-Shot Stop
Record Half Press AF: Start
Rocker + Press Iris: Open
Rocker - Press Iris: Closed
PRO I/O GPIO GPI A LOW Record: Toggle
GPI B Low Record: Toggle
SW 1 Low Go to: Playback
SW 2 Low Record: Toggle

RED Epic Specifications

General

Sensor	Mysterium-X
Resolution	5120 x 2700 (5K)
Lens Mount	PL Mount
Frame Rates	1-120 fps
Dynamic Range	13.5 stops
Recording Format	REDCODE RAW
Media	REDMAG (SSD)
Weight	5 lbs (2.3 kg) body only
Sensor Size	27.7 mm x 14.6 mm
Operating Temperature	32°F to 104°F (0°C to 40°C)
