Reer MZERO - Page 102

STAND ALONE PROGRAMMABLE SAFETY CONTROLLER
102 8541403 • 19/07/2021 • Rev.1
English
MZERO signals with Network operative
NETWORK FUNCTIONAL BLOCK SIGNALS
Network in
Network out (OSSD)
Network out
(STATUS)
Reset in
LED
FAIL EXT
IN (1)
OSSD (2)
STATUS
IN (3)
STATUS
STOP
OFF
OFF
RED
OFF
OFF
CLEAR
OFF
BLINKING
RED/GREEN (BLINKING)
BLINKING
BLINKING
RUN
OFF
ON
GREEN
ON
ON
FAIL
ON
BLINKING
-
-
-
(1) Corresponding to the input where is wired Network IN
(2) Corresponding to the input where is wired Network OUT
(3) Corresponding to the input where is wired Reset IN
Figure 40 - NETWORK function block scheme example (Category 2)
