Reer MZERO - Mzero 16.4 Pinout

STAND ALONE PROGRAMMABLE SAFETY CONTROLLER
8541403 • 19/07/2021 • Rev.1 11
English
MZERO 16.4 PINOUT
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
2
24VDC
-
24VDC power supply
-
3
NC
-
-
-
4
0VDC
-
0VDC power supply
-
5
OSSD1_A
Output
Static output 1
PNP active high
6
OSSD1_B
Output
PNP active high
7
RESTART_FBK1
Input
Feedback/Restart 1
Input (type 2) according to EN 61131-2
8
OUT_STATUS1
Output
SIL 1/PL c output
PNP active high
9
OSSD2_A
Output
Static output 2
PNP active high
10
OSSD2_B
Output
PNP active high
11
RESTART_FBK2
Input
Feedback/Restart 2
Input (type 2) according to EN 61131-2
12
OUT_STATUS2
Output
SIL 1/PL c output
PNP active high
13
OSSD3_A
Output
Static output 1
PNP active high
14
OSSD3_B
Output
PNP active high
15
RESTART_FBK3
Input
Feedback/Restart 1
Input (type 2) according to EN 61131-2
16
OUT_STATUS3
Output
SIL 1/PL c output
PNP active high
17
OSSD4_A
Output
Static output 2
PNP active high
18
OSSD4_B
Output
PNP active high
19
RESTART_FBK4
Input
Feedback/Restart 2
Input (type 2) according to EN 61131-2
20
OUT_STATUS4
Output
SIL 1/PL c output
PNP active high
21
OUT_TEST1
Output
Short circuit detection output
PNP active high
22
OUT_TEST2
Output
Short circuit detection output
PNP active high
23
OUT_TEST3
Output
Short circuit detection output
PNP active high
24
OUT_TEST4
Output
Short circuit detection output
PNP active high
25
INPUT1
Input
Digital input 1
Input (type 3) according to EN 61131-2
26
INPUT2
Input
Digital input 2
Input (type 3) according to EN 61131-2
27
INPUT3
Input
Digital input 3
Input (type 3) according to EN 61131-2
28
INPUT4
Input
Digital input 4
Input (type 3) according to EN 61131-2
29
INPUT5
Input
Digital input 5
Input (type 3) according to EN 61131-2
30
INPUT6
Input
Digital input 6
Input (type 3) according to EN 61131-2
31
INPUT7
Input
Digital input 7
Input (type 3) according to EN 61131-2
32
INPUT8
Input
Digital input 8
Input (type 3) according to EN 61131-2
33
INPUT9
Input
Digital input 9
Input (type 3) according to EN 61131-2
34
INPUT10
Input
Digital input 10
Input (type 3) according to EN 61131-2
35
INPUT11
Input
Digital input 11
Input (type 3) according to EN 61131-2
36
INPUT12
Input
Digital input 12
Input (type 3) according to EN 61131-2
37
INPUT13
Input
Digital input 13
Input (type 3) according to EN 61131-2
38
INPUT14
Input
Digital input 14
Input (type 3) according to EN 61131-2
39
INPUT15
Input
Digital input 15
Input (type 3) according to EN 61131-2
40
INPUT16
Input
Digital input 16
Input (type 3) according to EN 61131-2
Table 2
