OPERATOR FUNCTION BLOCKS
All the input of these operators could be inverted (logical NOT). It could be done clicking with the
right mouse key on the input to be inverted. A little circle will be showed on the inverted input. To
cancel the inversion, simply click another time on the same input pin.
➔ The maximum number of functional blocks is 64.
LOGICAL OPERATORS
AND
Logical AND returns an output of 1 (TRUE) if all the
inputs are 1 (TRUE).
In1
In2
Inx
Out
0
0
0
0
1
0
0
0
0
1
0
0
1
1
0
0
0
0
1
0
1
0
1
0
0
1
1
0
1
1
1
1
Parameters
Number of inputs: this is used to set between 2 and 8 inputs.
NAND
Logical NAND returns an output of 0 (FALSE) if all the
inputs are 1 (TRUE).
In1
In2
Inx
Out
0
0
0
1
1
0
0
1
0
1
0
1
1
1
0
1
0
0
1
1
1
0
1
1
0
1
1
1
1
1
1
0
Parameters
Number of inputs: this is used to set between 2 and 8 inputs.
