Reer MZERO - Operating Diagram

STAND ALONE PROGRAMMABLE SAFETY CONTROLLER
14 8541403 • 19/07/2021 • Rev.1
English
OPERATING DIAGRAM
Mechanical fastening
Electrical connections
between the MZERO and
external sensors
Designing the project
Validation
SW OK ?
NO
YES
Downloading the
project to MZERO
Configuration check
(including complete
system TEST)
on MZERO OK?
NO
YES
End of connection
via USB
System
startup
Connection
via USB with MZD
