Reer MZERO - Mzero Fail Codes

STAND ALONE PROGRAMMABLE SAFETY CONTROLLER
8541403 • 19/07/2021 • Rev.1 115
English
MZERO FAIL CODES
In case of malfunction the MZERO system transmits to the MZD software a code corresponding
to the error detected by the MZERO.
To read the code, proceed as follows:
connect the MZERO (indicating FAIL by led) to the PC using the USB cable;
- launch the software MZD;
- use the icon for the connection; a window appears to request the password; enter the
password; a window appears with the error code occurred.
The following table lists all possible errors detected and their solution.
CODE
FAIL
SOLUTION
19D, 20D
The two MZERO microcontrollers do not
see the same hw/sw configuration
CHECK CONNECTIONS
130D 135D
137D 138D
140D 194D
197D 198D
199D 201D
202D 203D
205D
Errors solid state output OSSD1
CHECK THE OSSD1 CONNECTIONS
144D 149D
151D 152D
154D 208D
211D 212D
213D 215D
216D 217D
219D
Errors solid state output OSSD2
CHECK THE OSSD2 CONNECTIONS
158D 163D
165D 166D
168D 222D
225D 226D
227D 229D
230D 232D
233D
Errors solid state output OSSD3
CHECK THE OSSD3 CONNECTIONS
172D 177D
179D 180D
182D 236D
239D 240D
241D 243D
244D 245D
247D
Errors solid state output OSSD4
CHECK THE OSSD4 CONNECTIONS
All other codes are related to errors or an internal malfunction. Please replace MZERO that gave the error or
return to ReeR for repair and/or debugging and inform REER at the time of shipment.
The following table lists all internal errors.
CODE
FAIL
SOLUTION
1D...31D
Microcontroller Error
TRY TO RESTART SYSTEM. IF ERROR PERSISTS, SEND
UNIT TO REER LABORATORY FOR REPAIR.
32D...63D
Mainboard Error
128D...143D
192D...205D
OSSD1 Error
TRY TO RESTART SYSTEM. IF ERROR PERSISTS, SEND
UNIT TO REER LABORATORY FOR REPAIR.
144D...159D
206D...219D
OSSD2 Error
160D...173D
220D...233D
OSSD3 Error
174D...188D
234D...247D
OSSD4 Error
