R8C/20 Group, R8C/21 Group 4. Special Function Registers (SFRs)
Rev.2.00 Aug 27, 2008 Page 19 of 458
REJ09B0250-0200
Table 4.5 SFR Information (5)
(1)
X: Undefined
NOTE:
1. The blank regions are reserved. Do not access locations in these regions.
Address Register Symbol After reset
0100h Timer RA Control Register TRACR 00h
0101h Timer RA I/O Control Register TRAIOC 00h
0102h Timer RA Mode Register TRAMR 00h
0103h Timer RA Prescaler Register TRAPRE FFh
0104h Timer RA Register TRA FFh
0105h
0106h LIN Control Register LINCR 00h
0107h LIN Status Register LINST 00h
0108h Timer RB Control Register TRBCR 00h
0109h Timer RB One-Shot Control Register TRBOCR 00h
010Ah Timer RB I/O Control Register TRBIOC 00h
010Bh Timer RB Mode Register TRBMR 00h
010Ch Timer RB Prescaler Register TRBPRE FFh
010Dh Timer RB Secondary Register TRBSC FFh
010Eh Timer RB Primary TRBPR FFh
010Fh
0110h
0111h
0112h
0113h
0114h
0115h
0116h
0117h
0118h Timer RE Counter Data Register TRESEC 00h
0119h Timer RE Compare Data Register TREMIN 00h
011Ah
011Bh
011Ch Timer RE Control Register 1 TRECR1 00h
011Dh Timer RE Control Register 2 TRECR2 00h
011Eh Timer RE Count Source Select Register TRECSR 00001000b
011Fh
0120h
0121h
0122h
0123h
0124h
0125h
0126h
0127h
0128h
0129h
012Ah
012Bh
012Ch
012Dh
012Eh
012Fh
0130h
0131h
0132h
0133h
0134h
0135h
0136h
0137h Timer RD Start Register TRDSTR 11111100b
0138h Timer RD Mode Register TRDMR 00001110b
0139h Timer RD PWM Mode Register TRDPMR 10001000b
013Ah Timer RD Function Control Register TRDFCR 10000000b
013Bh Timer RD Output Master Enable Register 1 TRDOER1 FFh
013Ch Timer RD Output Master Enable Register 2 TRDOER2 01111111b
013Dh Timer RD Output Control Register TRDOCR 00h
013Eh Timer RD Digital Filter Function Select Register 0 TRDDF0 00h
013Fh Timer RD Digital Filter Function Select Register 1 TRDDF1 00h
