R8C/20 Group, R8C/21 Group 7. Programmable I/O Ports

Rev.2.00 Aug 27, 2008 Page 46 of 458

REJ09B0250-0200

Figure 7.7 Configuration of Programmable I/O Ports (7)

P6_7

P6_6

INT2 input

Port latchData bus

Pull-up selection

Digital

filter

Output from each peripheral function

Direction

INT3 input

Port latchData bus

Pull-up selection

Digital

filter

Direction

Input to each peripheral function

(1)

NOTE:

1. symbolizes a parasitic diode.

Ensure the input voltage on each port will not exceed VCC.

(1)
