6.3.2 Error Codes
If a manufacturer-specific error occurs during the parameter access, the supple-
mentary error code provides pointers to the cause of the error. Excerpts of the
main error codes are listed in the following table:
Error number (hex) Meaning
0x03
Invalid parameter value
● Value is less than minimum value
● Value is greater than maximum value
● Value is not correct
● Invalid indirect addressing
● Command execution not possible (invalid or wrong parameters)
0x0E Parameter cannot be changed
0x0F Parameter is password protected
0x10
Parameter is write-protected
● Parameter currently write-protected
● Parameter is write-protected, as configured cyclically in the MDT
● Parameter write-protected on account of other settings (parameters,
operation mode, …)
● Command execution is not possible now (e.g. command cannot be
enabled in this phase)
0x13 Parameter transmitted for too short period
0x15 Parameter transmitted for too long period
0x1F
● Command is already active
● Command interruption is not possible
Tab. 6-2: Error codes
When parameter write access on the two bytes type parameter, any
values exceeding 65,535 (0xFFFF) will be reduced automatically to a
two bytes value. If the reduced two bytes value is in the valid range,
then it will be accepted without sending value exceed limits indica-
tion.
