4.2 Communication Channel Setting
The fieldbus communication channel should be configured according to the ac-
tual application when the MEP communication extension card is applied.
If the first control command and frequency setting are both transmitted via com-
munication channel, parameters in table 4-2 should be set to open the first com-
munication channel.
Code Name Value
E0.00 First frequency setting source 20: Communication
E0.01 First run command source 2: Communication
Tab. 4-2: First communication channel parameters
And if the second communication channel is used with the MEP extension card,
the parameters in table 4-3 should be set to open the second communication
channel.
Code Name Value
E0.02 Second frequency setting source 20: Communication
E0.03 Second run command source 2: Communication
Tab. 4-3: Second communication channel parameters
After configuration is completed for the communication channel, the parameter
E8.00 should be set to redirect to the communication extension card.
Code Name Value
E8.00 Communication protocol 1: Extension card
Tab. 4-4: Communication selection parameter
