6 EtherNet/IP
6.1 Protocol Configuration
The master communication address for EtherNet/IP is an IP address. It is set
manually in the frequency converter side by using an engineering tool. The pa-
rameter H3.06 can be set to enable the MEP in receiving IP address from a
DHCP server, see chapter 10.2.2.
Code Name
H3.00 MEP: MAC Address Device
H3.01 MEP: MAC Address Port 1
H3.02 MEP: MAC Address Port 2
H3.03 MEP: IP Address
H3.04 MEP: Subnet Mask
H3.05 MEP: Gateway Address
H3.06 MEP: IP Options
Tab. 6-1: IP-related parameters
Bosch Rexroth AG
EtherNet/IP
Multi-Ethernet Card
22/61
DOK-RCON0*-XFCX610*MUL-IT02-EN-P
