10.2 MEP Parameters
10.2.1 Terminology and Abbreviation
● Attri.: Parameter attribute
– Run: Parameter setting can be modified when the converter is in run or
stop state
– Stop: Parameter setting can only be modified when the converter is in stop
state
– Read: Parameter setting is read-only and cannot be modified
● <MANU>: Depend on manufacturing
● -: Not available
10.2.2 Parameter List
Function
Code
Parameter Name Data Type Factory Default Attri.
H3.00 MEP: MAC Address Device BYTE LIST <MANU> Read
H3.01 MEP: MAC Address Port 1 BYTE LIST <MANU> Read
H3.02 MEP: MAC Address Port 2 BYTE LIST <MANU> Read
H3.03 MEP: IP Address BYTE LIST 192.168.0.1 Run
H3.04 MEP: Subnet Mask BYTE LIST 255.255.255.0 Run
H3.05 MEP: Gateway Address BYTE LIST 0.0.0.0 Run
H3.06 MEP: IP Options DWORD 0 Run
H3.07
MEP: Local Hostname
(SERCOS/IP, EtherNet/IP)
CHAR LIST hostname Run
H3.08 MEP: Application Type CHAR LIST
Frequency Con-
verter
Read
H3.10 MEP: Device ID (PROFINET) WORD 0x2802 Read
H3.11 MEP: Order ID CHAR LIST <MANU> Read
H3.12 MEP: Product Name CHAR LIST MEP Read
H3.13 MEP: Serial Number ULONG <MANU> Read
H3.14 MEP: Product Code (EtherNet/IP) WORD 0x0024 Read
H3.18 MEP: Visual Status Indicators ULONG - Read
H3.20 MEP: Station Name (PROFINET) CHAR LIST axis01 Stop
H3.21 MEP: Station Type (PROFINET) CHAR LIST
Rexroth-Multi-
Ethernet
Read
H3.22 MEP: Subdevice ID (PROFINET) DWORD 0x011F2802 Read
H3.23 MEP: Device Address WORD 1 Run
H3.24 MEP: Active Device Address (Topology) WORD 0 Read
