Function
Code
Parameter Name Data Type Factory Default Attri.
H3.25 MEP: IP address is remnant (PROFINET) DWORD 0 Run
H3.26
MEP: EtherCAT List of Input Process Data
(Master)
WORD LIST 0x0000, 0x0000 Read
H3.27
MEP: EtherCAT List of Output Process Data
(Master)
WORD LIST 0x0000, 0x0000 Read
H3.28 MEP: Input Process Data Length (Master) USHORT 0 Read
H3.29 MEP: Output Process Data Length (Master) USHORT 0 Read
H3.30 MEP: List of Input Process Data WORD LIST 0x6001, 0x1002 Stop
H3.31 MEP: List of Output Process Data WORD LIST 0x6000, 0x600A Stop
H3.32 MEP: Input Process Data Length (Slave) USHORT 4 Read
H3.33 MEP: Output Process Data Length (Slave) USHORT 4 Read
H3.34 MEP: Communication Platform State DWORD - Read
H3.35 MEP: Communication Diagnosis Flags DWORD - Read
H3.36 MEP: ComCycle Periods [ns] ULONG 0,0,0 Read
H3.37 MEP: Communication Phase USHORT 0 Read
H3.40 MEP: Industrial Ethernet Protocol Request CHAR LIST S3 Run
H3.41 MEP: Industrial Ethernet Protocol Active CHAR LIST S3 Read
H3.42 MEP: Industrial Ethernet Protocol Logicware CHAR LIST S3L Read
H3.49 MEP: EtherCAT State USHORT 1 Read
H3.51 MEP: Modbus/TCP Alternative TCP port USHORT 0 Run
H3.63 MEP: List of external parameters WORD - Read
H3.71 MEP: Subsystem identification parameter CHAR LIST <MANU> Read
H3.96 MEP: FWA string CHAR LIST <MANU> Read
Tab. 10-3: Parameter List
● H3.06 MEP: IP Options
Bit 0: DHCP enabled (MEP receives IP address H3.03 from a DHCP server),
other Bits unused.
● H3.18 MEP: Visual Status Indicators
This parameter gives a data representation of the LED indications.
Bit
Name Function
31...18 - Reserved
17 Link P2 1 = Ethernet link present
0 = No Ethernet link
16 Link P1
Multi-Ethernet Card Bosch Rexroth AG
Parameters
DOK-RCON0*-XFCX610*MUL-IT02-EN-P
51/61
