Bit Name Description
17 FW CRC-OK
Communication Platform Firmware consistency check done
and status is OK.
16...15 - Reserved
14 PDC Invalid
Process Data Configuration contains unknown/unsupported
parameters or exceeds maximum data length of 15 parame-
ters for input and output data, each.
13 PDC Difference
Process Data Configuration of Communication Platform
([H3.30]/[H3.31]) and Process Data Configuration of Field-
bus Master are differing in data length.
12 Connection Timeout
An existing cyclic communication was terminated because of
missing master telegrams.
11 Connection Closed
An existing cyclic communication was closed by the fieldbus
master.
10 Connection Idle Fieldbus master set process data status to “invalid”.
9 Connection Error
An existing cyclic communication got broken because of a
communication problem.
8 Fieldbus Initiate Error Error while starting fieldbus stack
7...6 - Reserved
5 Identify Error Invalid identification parameters
4 DHCP Error DHCP request: No response from DHCP server.
3 MAC Address Error Invalid MAC address
2 IP Initiate Error Error while starting IP stack
1 IP Address Error IP address already present at subnet
0 Link Error No Ethernet link
Tab. 10-6: Parameter H3.35
● H3.36 MEP: ComCycle Periods [ns]
This parameter consists of three values that define current communication cy-
cle periods. All values are given in nanoseconds.
– Value 1: Transmission Cycle On Bus
– Value 2: Producer Cycle (Input Data Cycle)
– Value 3: Consumer Cycle (Output Data Cycle)
Multi-Ethernet Card
Bosch Rexroth AG
Parameters
DOK-RCON0*-XFCX610*MUL-IT02-EN-P
53/61
